Specifications
– Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
– Interface: 24 10/100Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
– Network Media: 10BASE-T: 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m), 100BASE-TX: UTP category 5, 5e or above cable (maximum 100m)
– Fan Quantity: Fanless
– Physical Security Lock: Yes
– Power Supply: 100-240VAC, 50/60Hz
– Power Consumption: Maximum: 3.2W
– Dimensions ( W x D x H ): 17.3*7.1*1.7 in. (440*180*44 mm)
– Mounting: Rack Mountable
– Max Power Consumption: 3.19W(220V/50Hz)
– Max Heat Dissipation: 10.88BTU/h
– Switching Capacity: 4.8Gbps
– Packet Forwarding Rate: 3.57Mpps
– MAC Address Table: 8K
– Buffer Memory: 2Mb
– Green Technology: Yes
– Transfer Method: Store-and-Forward
Package Contents
1x 24-Port 10/100Mbps Rackmount Switch
1x Power Cord
1x Installation Guide
1x Rackmount Kit
1x Rubber Feet
