Specifications
– Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3x
– Interface: 16 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
– Network Media: 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m), 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)
– Fan Quantity: Fanless
– Physical Security Lock: No
– Power Supply: 100-240VAC, 50/60Hz
– Power Consumption: Maximum: 9.26W (220V/50Hz)
– Dimensions ( W x D x H ): 17.3*7.1*1.7 in. (440*180*44 mm)
– Mounting: Rack Mountable
– Max Power Consumption: 9.26W(220V/50Hz)
– Max Heat Dissipation: 31.60BTU/h
– Switching Capacity: 32Gbps
– Packet Forwarding Rate: 23.8Mpps
– MAC Address Table: 8K
– Buffer Memory: 10KB
– Green Technology: Yes
– Transfer Method: Store-and-Forward
Package Contents
1x 16-Port 10/100Mbps Desktop/Rackmount Switch
1x Power Cord
1x Installation Guide
1x Rackmount Kit
1x Rubber Feet
